Ease EB760M B760M DDR5 LGA1700 Micro-ATX Motherboard

Name: Ease EB760M B760M DDR5 LGA1700 Micro-ATX Motherboard
Brand: Ease
SKU: EASE-EB760M
Price: 24999 PKR
Availability: InStock

Rs 24,999

In stock

1 year local warranty

SKU: EASE-EB760M
Category: Motherboards

Description

The B760M DDR5 LGA1700 Micro-ATX Motherboard is a well-rounded platform for Intel 12th, 13th, and 14th generation Core processors, pairing speedy DDR5 memory with modern expansion. A PCIe 4.0/5.0 x16 slot, 2.5Gbps LAN, and an M.2 Wi-Fi slot keep compact Intel builds fast and future-ready.

Key Features

Intel B760 chipset on LGA1700 for 12th, 13th, and 14th Gen Core CPUs
2 x DDR5 UDIMM slots supporting up to 64GB of memory
PCIe 4.0/5.0 x16 slot for high-bandwidth graphics cards
Realtek RTL8125B 2.5Gbps Ethernet for fast networking
M.2 Wi-Fi slot with CNVi support for easy wireless upgrades
HDMI and DisplayPort outputs in a compact Micro-ATX layout

Specifications

Spec	Value
Chipset	Intel B760
Socket	Intel LGA1700
CPU Support	Intel 12th / 13th / 14th Gen Core i3/i5/i7/i9, Pentium, Celeron
Memory	2 x DDR5 UDIMM, up to 4800MHz, max 64GB
Form Factor	Micro-ATX (190 x 230mm)
Storage	4 x SATA 3.0
Wireless	1 x M.2 Wi-Fi slot (CNVi support)
Expansion	1 x PCIe 4.0/5.0 x16, 1 x PCIe 3.0 x1
USB	1 x USB 3.2 Gen2, 2 x USB 3.2 Gen1, 4 x USB 2.0 (headers)
LAN	Realtek RTL8125B 2.5Gbps
Audio	Realtek ALC662 HD Audio
Display Output	HDMI, DisplayPort, optional VGA
