Hover to zoom · click for full image1200W fully modular ATX 3.1 PSU with native 12V-2x6, triple Platinum efficiency and a bundled EDGE Hub V2 fan/USB controller.
Colour · Black
The EDGE Platinum V2 1200W delivers serious headroom for high-end GPUs and overclocked CPUs while keeping the build clean, thanks to Lian Li's L-shaped chassis that relocates the cable bank to the side of the unit. A native 12V-2x6 (PCIe 5.1) connector powers demanding graphics cards over a single cable, and the single high-current +12V rail provides steady delivery under load.
Triple Platinum certification from 80 PLUS, Cybenetics and PPLP keeps efficiency high and heat low, so the 120mm fluid-dynamic-bearing fan can stay in zero-RPM silence at light loads. 100% Japanese capacitors and a full protection suite back the unit, while a removable magnetic dust filter with an LED cleaning reminder keeps intake airflow clean.
| Spec | Value |
|---|---|
| Wattage | 1200W continuous |
| Efficiency | 80 PLUS Platinum / Cybenetics Platinum / PPLP Platinum (up to 92% at 230V) |
| Form Factor | ATX (L-shaped) |
| ATX / PCIe Spec | ATX 3.1, PCIe 5.1 |
| Modularity | Fully modular |
| +12V Rail | Single rail, up to 100A |
| GPU Connector | Native 12V-2x6 (12VHPWR), up to 600W |
| CPU Power | Dual 4+4-pin EPS (12V) |
| PCIe Connectors | 3 x 6+2-pin PCIe |
| Cooling | 120mm FDB fan with 0 RPM zero-fan mode and physical fan on/off switch |
| Capacitors | 100% Japanese capacitors |
| Dust Filter | Removable magnetic dust filter with LED cleaning reminder (after 360 hours) |
| Included Hub | EDGE Hub V2 - magnetic USB 2.0 + PWM fan hub (6 PWM ports rated 2A each, 4 USB headers), managed in L-Connect 3 |
| Protections | OCP, OVP, OTP, OPP, SCP, UVP, SIP, NLP |
| Dimensions | 86(W) x 150(H) x 182(D)mm |
