Lian Li O11D EVO Upright GPU Bracket O11DE-6X Black, mounting frame
Hover to zoom · click for full image

Lian Li O11D EVO Upright GPU Bracket O11DE-6 (No Riser Cable)

Upright GPU bracket for the O11 Dynamic EVO (no riser cable), fits 3-slot cards up to 356mm, in Black or White

Rs 1,400
In stock

SKU: O11DE-6X

Color · Black

1
1 year local warranty
Price in Pakistan
Rs 1,400
Brand
Lian Li
Category
Stands & Mounts

Description

The Lian Li O11D EVO Upright GPU Bracket (O11DE-6) stands your graphics card upright beside the motherboard in the O11 Dynamic EVO, for a striking showcase and an open main chamber.

Key Features

  • Upright GPU mounting bracket in 1mm steel, made for the O11 Dynamic EVO chassis
  • Bracket-only version (O11DE-6X Black, O11DE-6W White): no PCIe riser cable included
  • Mounts on the HDD tray panel or the side fan bracket, in normal or reverse mode (GPU ports up or down)
  • Supports graphics cards up to 356mm long, 150mm wide and 3 slots (62mm) thick
  • Adjustable L-type support bracket adapts to the card's width and thickness
  • Moving the GPU beside the motherboard opens a chimney-style airflow path; on the fan bracket, fans behind the GPU exhaust its heat
  • Pairs with Lian Li's 600mm PCIe 4.0 riser cable (PW-PCI-4-60X/W, sold separately)
  • Thicker, longer non-reference RTX 40-series cards need Lian Li's O11DE-10 supplemental kit (sold separately)

Show off your graphics card upright in the O11 Dynamic EVO, in Black or White.

Specifications

Spec Value
Type Upright / vertical GPU mounting bracket
Model No. O11DE-6X (Black), O11DE-6W (White)
Compatible case O11 Dynamic EVO
Mounting position HDD tray panel or side fan bracket, normal or reverse mode
Max GPU length 356mm
Max GPU thickness 3 slots (62mm)
Max GPU width 100 to 150 mm (121 to 150 mm on the fan bracket)
Material 1mm steel
Mounting frame 71.8 x 128 x 67.58 mm (L x D x H)
Support frame 70 x 81 x 10 mm (L x D x H)
Riser cable Not included (bracket only)
Recommended riser 600mm PCIe 4.0 (PW-PCI-4-60X/W), sold separately
Colours Black, White
