Lian Li RB-550B 550W 80+ Bronze ATX 3.1 power supply in black, angled view with Velcro cable straps
Hover to zoom · click for full image

Lian Li RB Series RB-550B 550W 80+ Bronze ATX 3.1 Power Supply (Black)

Compact 150mm semi-modular ATX 3.1 PSU in black with two PCIe 6+2-pin GPU connectors

Rs 14,500
In stock
1
1 year local warranty
SKU
G9P.RB0550B.B000.UK
Price in Pakistan
Rs 14,500
Brand
Lian Li
Category
Power Supplies

Description

The RB-550B is Lian Li's compact 150mm, 80 PLUS Bronze power supply in black for everyday gaming and productivity PCs: it is built to the ATX 3.1 standard and powers the graphics card through two PCIe 6+2-pin connectors.

Key Features

  • 550W output, 80 PLUS Bronze certified with up to 85% efficiency
  • ATX 3.1 with two PCIe 6+2-pin GPU connectors (no 12V-2x6 cable)
  • Semi-modular: the 24-pin ATX, CPU EPS and PCIe cables are fixed, while the SATA and peripheral cable plugs in only when you need it
  • Built-in routing channel and Velcro straps on three sides of the housing keep cables tidy, ideal for back-connect motherboards and compact cases
  • Compact 150mm depth for wide ATX case compatibility
  • 135mm HYB temperature-controlled fan for quiet cooling
  • 105°C capacitors, a single high-amperage +12V rail and DC-to-DC design for stable output
  • Six protections: OVP, UVP, OCP, OPP, OTP and SCP

It has no 12V-2x6 (16-pin) cable; that comes on the 650W and 750W models. A tidy, quiet choice for builds whose graphics card takes standard PCIe 6+2-pin power.

Specifications

Spec Value
Model RB0550B
Wattage 550W
Form Factor ATX
ATX Specification ATX 3.1
Efficiency 80 PLUS Bronze (up to 85% efficiency)
Type Semi-Modular (fixed 24-pin ATX, CPU EPS and PCIe 6+2-pin; modular SATA and peripheral)
Main Connectors 1x 20+4-pin ATX (600mm), 2x CPU EPS 4+4-pin (650mm), 2x PCIe 6+2-pin on one cable (600mm + 150mm), 3x SATA + 1x PATA (Molex) on one cable
12V-2x6 (16-pin) Cable Not included
+12V Rail Single rail, 45.8A (549.6W combined)
+3.3V & +5V Combined 100W
Input 100-240Vac, 8A, 50-60Hz, Active PFC (PF > 0.95 at full load)
Cooling Fan 135mm HYB temperature-controlled fan, 1300 RPM
Noise Level 33.2 dBA
Capacitors 105°C
Protections OVP, UVP, OCP, OPP, OTP, SCP
MTBF 100,000 hours (25°C, 75% load)
Dimensions (D x W x H) 150 x 86 x 150mm
Colour Black
