750W 80 PLUS Bronze, ATX 3.1 with native 12V-2x6, semi-modular, compact 150mm, black
The Lian Li RB-750B is a compact 750W, 80 PLUS Bronze ATX 3.1 power supply in classic black, with the headroom and native 12V-2x6 cable that high-performance gaming and workstation builds need.
Note: the 12V-2x6 plug has a two-tone housing. Push it in until the blue part is fully inserted for a secure connection.
A tidy black power supply with real headroom for a modern gaming PC.
| Spec | Value |
|---|---|
| Model | RB0750B |
| Wattage | 750W |
| Form Factor | ATX |
| ATX Specification | ATX 3.1 |
| Efficiency | 80 PLUS Bronze (up to 85%) |
| Type | Semi-Modular (fixed 24-pin ATX, CPU EPS and GPU cables; modular SATA and peripheral) |
| Main Connectors | 24-pin (20+4) ATX, CPU 4+4-pin EPS, native 12V-2x6 (16-pin), PCIe 6+2-pin, SATA, PATA (Molex), plus an extra 100mm 12V-2x6 to PCIe 6+2-pin cable |
| +12V Rail | Single rail, 62.5A (750W combined) |
| +3.3V & +5V Combined | 100W |
| AC Input | 100-240Vac, 10A, 50-60Hz |
| PFC | Active PFC, PF > 0.95 at full load |
| Cooling Fan | 135mm HYB temperature-controlled fan, 1600rpm |
| Noise Level | 40.1dBA |
| Capacitors | 105°C |
| MTBF | 100,000 hours minimum |
| Protections | OVP, UVP, OCP, OPP, OTP, SCP |
| Safety Approvals | CE, CB, cTUVus, TÜV, FCC, BSMI, CCC, KCC, SAA+RCM |
| Dimensions (D x W x H) | 150 x 86 x 150mm |
| Colour | Black |
