MSI B860M GAMING WIFI

Name: MSI B860M GAMING WIFI
Brand: MSI
SKU: MSI-B860M-GAMING-WIFI
Price: 48500 PKR
Availability: InStock

Rs 48,500

In stock

1 year local warranty

SKU: MSI-B860M-GAMING-WIFI
Category: Motherboards

Description

The MSI B860M GAMING WIFI is a micro-ATX motherboard built on the Intel B860 chipset for Intel Core Ultra (Series 2) processors, featuring PCIe 5.0 and a Gen5 M.2 slot. It is a compact gaming platform ready for the latest Intel desktop CPUs.

Key Features

LGA 1851 socket for Intel Core Ultra Series 2 processors
Two DDR5 DIMM slots supporting up to 128GB, rated to 9066 MHz and above with overclocking
PCIe 5.0 x16 slot for next generation graphics cards
Two M.2 slots, one Gen5 x4 and one Gen4 x4, for very fast NVMe storage
Four SATA 6Gb/s ports for additional drives
Realtek 8126 5G LAN plus Wi-Fi 7 with Bluetooth 5.4
USB Type-C at 20Gbps and Realtek ALC897 7.1 channel audio

A compact B860 gaming board with PCIe 5.0 and Wi-Fi 7 for Intel Core Ultra.

Specifications

Spec	Value
Type	Micro-ATX motherboard
Socket	LGA 1851
Chipset	Intel B860
CPU support	Intel Core Ultra Series 2
Memory	2x DDR5, up to 128GB, 9066+ MHz (OC)
Graphics slot	1x PCIe 5.0 x16
M.2	1x Gen5 x4, 1x Gen4 x4
SATA	4x SATA 6Gb/s
LAN	Realtek 8126 5G
Wireless	Wi-Fi 7 with Bluetooth 5.4
Audio	Realtek ALC897 (7.1 channel)
Display	HDMI 2.1, DisplayPort 1.4
