Hover to zoom · click for full imageMicro-ATX AMD B650 motherboard for Socket AM5 Ryzen CPUs with DDR5, PCIe 5.0 M.2 and 2.5G LAN.
The Sapphire B650M-E is a feature rich Micro-ATX motherboard for the AMD Socket AM5 platform, supporting Ryzen 9000, 8000 and 7000 Series desktop processors. The B650 chipset unlocks faster storage and networking for serious gaming and content creation builds.
A 6+2+1 phase CPU power design rated at 60A per phase, combined with VRM, M.2 and PCH heatsinks, keeps high core count Ryzen processors running cool and stable under heavy workloads.
A PCIe 5.0 M.2 slot is ready for the fastest next generation NVMe SSDs, backed by a second PCIe 4.0 M.2 slot and four SATA ports. Two DIMM slots run dual channel DDR5 up to 96GB at speeds reaching 7600 MHz (OC).
Onboard Realtek RTL8125BG 2.5 Gigabit Ethernet delivers fast, low latency networking, while the PCIe 4.0 x16 slot feeds your graphics card. Rear I/O includes HDMI and DisplayPort outputs, USB 3.2 Gen1 and USB 2.0 Type-A ports, and Realtek ALC897 5.1 channel HD audio. A four stage debug LED helps diagnose boot issues quickly.
| Specification | Detail |
|---|---|
| Chipset | AMD B650 |
| CPU Socket | AMD AM5 (Ryzen 9000 / 8000 / 7000 Series) |
| Form Factor | Micro-ATX (244 x 235 mm) |
| Memory | 2x DDR5 DIMM, dual channel, up to 96GB (2x 48GB), 7600 MHz (OC) |
| PCIe Slots | 1x PCIe 4.0 x16, 1x PCIe 4.0 x4 |
| Storage | 1x M.2 (PCIe 5.0), 1x M.2 (PCIe 4.0), 4x SATA III |
| LAN | Realtek RTL8125BG 2.5 Gigabit Ethernet |
| Audio | Realtek ALC897 HD Audio (5.1 channel) |
| Display Outputs | HDMI, DisplayPort |
| Rear USB | 2x USB 3.2 Gen1 Type-A, plus USB 2.0 |
| VRM | 6+2+1 phase CPU power, 60A per phase |
| Debug | 4-stage debug LED (DRAM, CPU, GPU, Boot) |
